SMD Power Choke SCDR-103RTL~105RTL Type

SMD Power Choke SCDR-103RTL~105RTL Type
SMD Power Choke SCDR-103RTL~105RTL Type
Send Inquiry
Product Code : 42
Brand Name : Upbeat
Price And Quantity
  • Minimum Order Quantity
  • 1100 Box
  • Price
  • 0.03-0.30 USD ($)
Product Specifications
  • Product Type
  • SCDR-103RTL~105RTL
  • Application
  • Power supply for VTR, OA equipment LCD television set, notebook PC Portable communication, equipment DC/DC converters, etc.
  • Size
  • SCDR103:10.3X10.5X3.10 ; SCDR104:10.3X10.5X4.00 ; SCDR105:10.3X10.5X5.10
  • Function
  • Power supply for VTR, OA equipment LCD television set, notebook PC Portable communication, equipment DC/DC converters, etc.
Product Description

Dimension in mm

TYPE

A

B

C

D

E

F

G

H

I

J

Max

Max

Max

Ref

Ref

Ref

Max

Ref

Ref

Ref

103

10.3

10.5

3.1

1.2

7.7

3

13.5

3.2

1.6

7.3

104

10.3

10.5

4

1.2

7.7

3

13.5

3.2

1.6

7.3

105

10.3

10.5

5.1

1.2

7.7

3

13.5

3.2

1.6

7.3

Standard Specification

Stamp

Inductance (uH)

SCDR103

SCDR104

SCDR105

DCR (mΩ)

Isat (A)

DCR (mΩ)

Isat (A)

DCR (mΩ)

Isat (A)

Max

Typ

Max

Typ

Max

Typ

1R0

1

　

　

7.5

10.5

　

　

1R5

1.5

11

8

8.5

9.5

6.5

9

1R8

1.8

　

　

9.5

9

　

　

2R2

2.2

17

6.7

10.5

7.5

8.5

7.5

2R5

2.5

　

　

10.5

7.5

　

　

3R3

3.3

21

5.56

13

6

10.4

7.8

3R8

3.8

　

　

15

6

　

　

4R7

4.7

30

4.65

20

5.7

13

6.1

5R2

5.2

　

　

23

5.5

　

　

5R6

5.6

　

　

27

5

　

　

6R8

6.8

35

3.84

27

5

18

5.4

7R0

7

　

　

27

4.8

　

　

8R2

8.2

50

3.54

33

4.5

20

5

100

10

59

3.18

35

4.4

26

4.5

120

12

　

　

46

4

33

3.8

150

15

91

2.6

50

3.6

41

3.4

180

18

　

　

70

3.1

46

3.1

220

12

143

2.16

73

2.9

61

2.9

270

27

　

　

89

2.6

69

2.6

330

33

202

1.74

93

2.3

84

2.5

390

39

　

　

125

2.2

106

2.3

470

47

299

1.43

128

2.1

130

2

560

56

325

1.36

188

1.65

149

1.9

680

68

429

1.22

213

1.5

201

1.65

820

82

494

1.14

300

1.4

227

1.5

101

100

683

1.02

304

1.35

253

1.35

121

120

754

0.89

420

1.18

303

1.28

151

150

871

0.84

506

1.15

370

1.12

181

180

　

　

680

1

419

1.04

221

220

　

　

756

0.92

500

0.94

271

270

　

　

　

　

672

0.84

331

330

　

　

1090

0.7

812

0.75

391

390

　

　

　

　

953

0.7

471

470

　

　

1350

0.6

1289

0.6

561

560

　

　

　

　

1430

0.54

681

680

　

　

2400

0.45

1599

0.52

821

820

　

　

3800

0.43

1768

0.5

102

1000

　

　

4420

0.4

1989

0.48
Trade Information
  • FOB Port
  • Tao-Yuan airport
  • Payment Terms
  • Telegraphic Transfer (T/T)
  • Supply Ability
  • 500K Per Week
  • Delivery Time
  • 6-8 Week
  • Sample Available
  • Yes
  • Sample Policy
  • Within a certain price range free samples are available
  • Packaging Details
  • Tapped & Reeled
  • Main Export Market(s)
  • Western Europe, North America, Australia, Asia
  • Certifications
  • ISO9001/ISO14000/TS16949
